Selection of site for construction of a Grid Sub Station is the first and important activity. This needs meticulous planning, fore-sight, skillful observation and handling so that the selected site is technically, environmentally, economically and socially optimal and is the best suited to the requirements.
The main points to be considered in the selection of site for construction of a Grid Sub Station are given below. The site should be: a) As near the load centre as possible.
Red eyex32 bo1 error download#
#RED EYEX32 BO1 DOWNLOAD FREE#ī)Īs far as possible rectangular or square in shape for ease of proper orientation of bus – bars and feeders.įar away from obstructions, to permit easy and safe approach / termination of high voltage overhead transmission lines.įree from master plans / layouts or future development activities to have free line corridors for the present and in future.Įasily accessible to the public road to facilitate transport of material.Īs far as possible near a town and away from municipal dumping grounds, burial grounds, tanneries and other obnoxious areas. This facilitates reduction in leveling expenditure.Ībove highest flood level (HFL) so that there is no water logging.
Sufficiently away from areas where police and military rifle practices are held. The site should have as far as possible good drinking water supply for the station staff. The site of the proposed Sub Station should not be in the vicinity of an aerodrome. The distance of a Sub Station from an aerodrome should be maintained as per regulations of the aerodrome authority. Approval in writing should be obtained from the aerodrome authority in case the Sub Station is proposed to be located near an aerodrome.
